Axelent is one of the market's leading manufacturers of machine guards. The complete system that we deliver meets current directives and standards.
Accessories
An infill sheet metal functions as a filler when a guard needs a certain width. Fixed infill pieces are available for all heights and in 40 and 70 mm widths. The adjustable infill piece covers gaps between 40 and 145 mm, offering greater flexibility. The 100 mm interval between our panels means l...
Fixed infill sheet metal
| CAD | Article | Height x Width (mm) | Height (mm) | |
|---|---|---|---|---|
|
|
T02-3-07504 | 750x40 | 750 |
1
|
|
|
T02-3-07507 | 750x70 | 750 |
1
|
|
|
T02-3-13004 | 1300x40 | 1300 |
1
|
|
|
T02-3-13007 | 1300x70 | 1300 |
1
|
|
|
T02-3-19004 | 1900x40 | 1900 |
1
|
|
|
T02-3-19007 | 1900x70 | 1900 |
1
|
|
|
T02-3-22004 | 2200x40 | 2200 |
1
|
|
|
T02-3-22007 | 2200x70 | 2200 |
1
|
Adjustable infill sheet metal
| CAD | Article | Description | Height (mm) | |
|---|---|---|---|---|
|
|
T05-3-07515 | 40-145 mm | 750 |
2
1
|
|
|
T05-3-13015 | 40-145 mm | 1300 |
2
1
|
|
|
T05-3-19015 | 40-145 mm | 1900 |
2
1
|
|
|
T05-3-22015 | 40-145 mm | 2200 |
2
1
|
|
|
T05-3-24015 | 40-145 mm | 2400 |
2
1
|
An infill sheet metal functions as a filler when a guard needs a certain width. Fixed infill pieces are available for all heights and in 40 and 70 mm widths. The adjustable infill piece covers gaps between 40 and 145 mm, offering greater flexibility. The 100 mm interval between our panels means less cutting of panels when an ‘odd’ gap needs to be filled. The standard colour is black (RAL 9011), but customised colours are available upon request.
